TL5001MJGB - Texas Instruments

Description: DC DC Cntrlr Single-OUT PWM DC to DC Controller 3.6V to 40V Input 8-Pin CDIP Tube

Download TL5001MJGB Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TL5001MJGB - Texas Instruments PCB footprint - Ceramic Dual-In-Line Packages - Ceramic Dual-In-Line Packages - JG  (R-GDIP-T8)
click to zoom
3D Models
TL5001MJGB - Texas Instruments  - 3D model - Ceramic Dual-In-Line Packages - JG  (R-GDIP-T8)
click to zoom

TL5001MJGB Details

  • Manufacturer Part Number:

    TL5001MJGB

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DIP

  • Pin Count:

    8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.33.00.01

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Analog IC - Other Type:

    SWITCHING CONTROLLER

  • Control Mode:

    VOLTAGE-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    40 V

  • Input Voltage-Min:

    3.6 V

  • Input Voltage-Nom:

    6 V

  • JESD-30 Code:

    R-GDIP-T8

  • JESD-609 Code:

    e0

  • Length:

    9.58 mm

  • Number of Functions:

    1

  • Number of Outputs:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -55 °C

  • Output Current-Max:

    3 A

  • Output Voltage-Max:

    50 V

  • Output Voltage-Min:

    1 V

  • Package Body Material:

    CERAMIC, GLASS-SEALED

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP8,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    5.08 mm

  • Supply Current-Max (Isup):

    2.1 mA

  • Surface Mount:

    NO

  • Switcher Configuration:

    BUCK-BOOST

  • Switching Frequency-Max:

    400 kHz

  • Temperature Grade:

    MILITARY

  • Terminal Finish:

    Tin/Lead (Sn/Pb)

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Width:

    7.62 mm

TL5001MJGB Frequently Asked Questions (FAQs)

  • It is recommended to place the TL5001MJGB close to the power source, use a solid ground plane, and keep the input and output traces separate to minimize noise and EMI. Additionally, use a decoupling capacitor (e.g., 10nF) between VCC and GND, and consider using a ferrite bead or inductor in series with the input voltage to filter out high-frequency noise.
  • To ensure stability, make sure to follow the recommended operating conditions, including input voltage, output load, and temperature range. Also, ensure that the output capacitor is properly sized and placed close to the output pin. A minimum output capacitance of 10uF is recommended. Additionally, consider adding a small resistor (e.g., 10Ω) in series with the output capacitor to dampen oscillations.
  • Although the datasheet specifies a maximum input voltage of 18V, it's recommended to limit the input voltage to 15V to ensure reliable operation and prevent damage to the device. Exceeding 15V may cause the device to malfunction or fail.
  • The TL5001MJGB is rated for operation up to 125°C, but it's essential to consider the device's power dissipation and thermal management when operating in high-temperature environments. Ensure that the device is properly heatsinked, and the ambient temperature is within the recommended range to prevent thermal shutdown or damage.
  • To troubleshoot issues, start by verifying the input voltage, output load, and operating temperature are within the recommended ranges. Check for proper PCB layout, decoupling, and output capacitance. Use an oscilloscope to monitor the input and output waveforms, and ensure that the device is not overheating. Consult the datasheet and application notes for guidance on specific troubleshooting steps.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

TL5001MJGB Overview

Use the download button to access the TL5001MJGB schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TL500, or try a keyword search, such as Switching Regulator or Controllers
