Texas Instruments recommends a star-ground configuration, with the analog and digital grounds separated and connected at a single point. Additionally, keep the input and output traces short and away from noise sources, and use a solid ground plane to reduce electromagnetic interference (EMI).
The TLE2022MDR has a maximum junction temperature of 150°C. To ensure reliable operation, maintain a safe margin between the operating temperature and the maximum junction temperature. Use thermal vias, heat sinks, and thermal interface materials as needed to dissipate heat. Also, consider derating the device's power consumption at high temperatures.
Power up the VCC supply before the input signals, and ensure that the input signals are stable and within the recommended voltage range before applying VCC. Also, avoid applying input signals before VCC is stable, as this can cause latch-up or other issues.
Use an oscilloscope to monitor the input and output signals, and check for noise, ringing, or other anomalies. Verify that the power supply is stable and within the recommended range, and that the input signals are within the recommended voltage range. Also, check for layout and routing issues, such as capacitive coupling or inductive noise.
The TLE2022MDR is not specifically designed or qualified for radiation-hardened or high-reliability applications. However, Texas Instruments offers other devices that are designed and qualified for such applications. Consult the Texas Instruments website or contact their support team for more information.
