TLE7182EM - Infineon

Description: Motor / Motion / Ignition Controllers & Drivers DRIVER_IC

Download TLE7182EM Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TLE7182EM - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - PG-SSOP24-4
click to zoom
3D Models
TLE7182EM - Infineon  - 3D model - Small Outline Packages - PG-SSOP24-4
click to zoom

TLE7182EM Details

  • Manufacturer Part Number:

    TLE7182EM

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    SSOP

  • Package Description:

    GREEN, PLASTIC, SSOP-24

  • Pin Count:

    24

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    8

  • Analog IC - Other Type:

    HALF BRIDGE BRUSH DC MOTOR CONTROLLER

  • JESD-30 Code:

    R-PDSO-G24

  • JESD-609 Code:

    e3

  • Length:

    8.65 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    24

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HLSSOP

  • Package Equivalence Code:

    SSOP24,.24

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE, HEAT SINK/SLUG, LOW PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    1.7 mm

  • Supply Voltage-Max (Vsup):

    45 V

  • Supply Voltage-Min (Vsup):

    5.5 V

  • Supply Voltage-Nom (Vsup):

    12 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Tin (Sn)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Width:

    3.9 mm

TLE7182EM Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the TLE7182EM is -40°C to 150°C.
  • To ensure proper cooling, the TLE7182EM should be mounted on a heat sink with a thermal resistance of ≤ 10 K/W. Additionally, the device should be placed in a well-ventilated area to prevent overheating.
  • The recommended PCB layout for the TLE7182EM involves placing the device near the power source, using wide traces for power and ground, and keeping the input and output pins separate to minimize noise and EMI.
  • To protect the TLE7182EM from overvoltage and undervoltage conditions, use a voltage regulator or a voltage supervisor to ensure the input voltage remains within the recommended range of 4.5V to 18V.
  • The maximum current rating for the TLE7182EM is 2A, but this can be increased to 4A with proper heat sinking and cooling.
