TLE7189QKXUMA1 - Infineon

Description: INFINEON - TLE7189QKXUMA1 - MOSFET Driver, Half Bridge, 5.5V to 28V Supply, 1.5A Out, 190ns Delay, LQFP-64

Download TLE7189QKXUMA1 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TLE7189QKXUMA1 - Infineon PCB footprint - Quad Flat Packages - Quad Flat Packages - PG-LQFP-64_2022
click to zoom
3D Models
TLE7189QKXUMA1 - Infineon  - 3D model - Quad Flat Packages - PG-LQFP-64_2022
click to zoom

TLE7189QKXUMA1 Details

  • Manufacturer Part Number:

    TLE7189QKXUMA1

  • Pbfree Code:

    No

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Part Package Code:

    QFP

  • Package Description:

    GREEN, PLASTIC, LQFP-64

  • Pin Count:

    64

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.31.00.01

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    0

  • Analog IC - Other Type:

    AC MOTOR CONTROLLER

  • JESD-30 Code:

    S-PQFP-G64

  • JESD-609 Code:

    e4

  • Length:

    10 mm

  • Number of Functions:

    1

  • Number of Terminals:

    64

  • Output Current-Max:

    0.01 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HLFQFP

  • Package Shape:

    SQUARE

  • Package Style:

    FLATPACK, HEAT SINK/SLUG, LOW PROFILE, FINE PITCH

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.6 mm

  • Supply Voltage-Max (Vsup):

    20 V

  • Supply Voltage-Min (Vsup):

    5.5 V

  • Supply Voltage-Nom (Vsup):

    14 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Width:

    10 mm

TLE7189QKXUMA1 Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the TLE7189QKXUMA1 is -40°C to 150°C.
  • To ensure the stability of the output voltage, it is recommended to use a minimum output capacitance of 10uF and a maximum ESR of 1 ohm, and to follow the layout guidelines provided in the datasheet.
  • The maximum input voltage that the TLE7189QKXUMA1 can handle is 40V.
  • The TLE7189QKXUMA1 has a built-in overcurrent protection feature that limits the output current to a maximum of 2.5A. Additionally, it is recommended to add external overcurrent protection devices, such as fuses or PTCs, to protect the device from excessive current.
  • The typical quiescent current of the TLE7189QKXUMA1 is 50uA.
