TLP2210 - Toshiba

TLP2210 Details

• Manufacturer Part Number:

  TLP2210

• Part Life Cycle Code:

  Active

• Package Description:

  SOP-8

• HTS Code:

  8541.40.80.00

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  9

• Additional Feature:

  UL RECOGNIZED

• Configuration:

  SEPARATE, 2 CHANNELS

• Data Rate-Nom:

  5 MBps

• Forward Current-Max:

  0.008 A

• Isolation Voltage-Max:

  5000 V

• Mounting Feature:

  SURFACE MOUNT

• Number of Elements:

  2

• Number of Functions:

  1

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Optoelectronic Device Type:

  LOGIC IC OUTPUT OPTOCOUPLER

• Response Time-Nom:

  1.1e-8 ns

• Supply Voltage-Min:

  2.7 V

• Surface Mount:

  YES
