TLP250H(D4-TP1,F) - Toshiba

Description: Logic Output Optocouplers Photocoupler, Photo IC Output

Download TLP250H(D4-TP1,F) Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TLP250H(D4-TP1,F) - Toshiba PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - 11-10C4 (8PDIP)
click to zoom
3D Models
TLP250H(D4-TP1,F) - Toshiba  - 3D model - Dual-In-Line Packages - 11-10C4 (8PDIP)
click to zoom

TLP250H(D4-TP1,F) Details

  • Manufacturer Part Number:

    TLP250H(D4-TP1,F)

  • Part Life Cycle Code:

    Active

  • Package Description:

    DIP-8

  • HTS Code:

    8541.40.80.00

  • Manufacturer:

    Toshiba America Electronic Components

  • YTEOL:

    7

  • Additional Feature:

    UL APPROVED, VDE APPROVED

  • Configuration:

    COMPLEX

  • Forward Current-Max:

    0.02 A

  • Isolation Voltage-Max:

    3750 V

  • Mounting Feature:

    THROUGH HOLE MOUNT

  • Number of Elements:

    1

  • Number of Functions:

    1

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Optoelectronic Device Type:

    LOGIC IC OUTPUT OPTOCOUPLER

  • Packing Method:

    TAPE

  • Response Time-Nom:

    5e-8 ns

  • Supply Voltage-Min:

    10 V

  • Surface Mount:

    NO

TLP250H(D4-TP1,F) Frequently Asked Questions (FAQs)

  • The recommended PCB layout for the TLP250H is to use a ground plane under the device, and to keep the input and output traces as short as possible to minimize noise and electromagnetic interference (EMI). Additionally, it is recommended to use a 0.1uF bypass capacitor between the VCC pin and ground to filter out high-frequency noise.
  • To handle the high current surge during output switching, it is recommended to use a low-ESR capacitor (e.g. ceramic or film capacitor) between the output pin and ground. This helps to reduce the voltage drop and ringing during switching. Additionally, the PCB layout should be designed to minimize the inductance of the output trace to reduce the voltage drop and ringing.
  • The maximum allowable voltage on the input pin of the TLP250H is 5.5V. Exceeding this voltage may cause damage to the device. It is recommended to use a voltage limiter or a resistor divider network to ensure that the input voltage does not exceed 5.5V.
  • To ensure reliable operation at high temperatures, it is recommended to follow the recommended operating conditions specified in the datasheet. Additionally, the device should be mounted on a heat sink or a thermally conductive PCB to dissipate heat effectively. It is also recommended to use a thermistor or a temperature sensor to monitor the device temperature and take corrective action if it exceeds the recommended operating temperature range.
  • The recommended input signal rise and fall time for the TLP250H is 10ns or faster. Slower rise and fall times may cause the device to malfunction or oscillate. It is recommended to use a signal with a fast rise and fall time to ensure reliable operation.
