Toshiba recommends a PCB layout with a solid ground plane, short traces, and minimal inductance to ensure high-speed signal integrity and minimize electromagnetic interference (EMI). A 4-layer PCB with a dedicated ground plane is recommended.
The TLP2704 has a thermal pad on the bottom of the package, which should be connected to a thermal ground plane on the PCB. Additionally, ensure good airflow around the device and consider using a heat sink if the device is expected to operate at high temperatures or high currents.
The maximum cable length supported by the TLP2704 depends on the specific application and the type of cable used. As a general guideline, Toshiba recommends keeping the cable length below 10 meters for reliable operation. However, this can be extended to 20 meters or more with proper cable selection and termination.
The TLP2704 is rated for operation up to 30V, but it's not recommended to use it in high-voltage applications above 24V without proper protection and voltage regulation. Exceeding the recommended voltage rating can lead to device damage or failure.
To ensure EMC, follow proper PCB layout and design guidelines, use shielding and filtering as necessary, and ensure that the device is properly grounded. Additionally, consider using a common-mode choke or other EMI filtering components to reduce electromagnetic radiation.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TLP2704 Overview
Use the download button to access the TLP2704 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TLP27,
or try a keyword search, such as Optocoupler
