TLP2955F(F) - Toshiba

Description: Toshiba TLP2955F(F) Photo IC Output Photocoupler, Through Hole, 8-Pin DIP

Download TLP2955F(F) Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TLP2955F(F) - Toshiba PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - 11-10C402S
click to zoom
3D Models
TLP2955F(F) - Toshiba  - 3D model - Dual-In-Line Packages - 11-10C402S
click to zoom

TLP2955F(F) Details

  • Manufacturer Part Number:

    TLP2955F(F)

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    DIP-8

  • HTS Code:

    8541.40.80.00

  • Manufacturer:

    Toshiba America Electronic Components

  • YTEOL:

    0

  • Configuration:

    SINGLE

  • Forward Current-Max:

    0.025 A

  • Isolation Voltage-Max:

    5000 V

  • Mounting Feature:

    THROUGH HOLE MOUNT

  • Number of Elements:

    1

  • Number of Functions:

    1

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Optoelectronic Device Type:

    LOGIC IC OUTPUT OPTOCOUPLER

  • Power Dissipation-Max:

    0.1 W

  • Response Time-Max:

    7.5e-8 s

  • Response Time-Nom:

    1.6e-8 ns

  • Supply Voltage-Min:

    3 V

  • Supply Voltage-Nom:

    20 V

  • Surface Mount:

    NO
