Toshiba recommends a PCB layout with a solid ground plane, short traces, and minimal vias to reduce noise and ensure signal integrity. A 4-layer PCB with a dedicated power plane and a separate ground plane is recommended.
The TLP3063 requires a bias voltage of 3.3V to 5V on the VCC pin, and a bias current of 10mA to 20mA on the VEE pin. Ensure that the bias voltage and current are within the recommended range to achieve optimal performance.
The TLP3063 has an operating temperature range of -40°C to 125°C. However, the device's performance may degrade at extreme temperatures, and it's recommended to operate within the recommended temperature range for optimal performance.
The TLP3063 has built-in ESD protection, but it's still recommended to follow proper ESD handling procedures during assembly and testing. Use an ESD wrist strap or mat, and ensure that the device is handled in a static-free environment.
The TLP3063 should be stored in a dry, cool place with a temperature range of 5°C to 30°C and a relative humidity of 60% or less. Avoid storing the device in direct sunlight or near heat sources.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TLP3063 Overview
Use the download button to access the TLP3063 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TLP30,
or try a keyword search, such as Optocoupler
