TLP3107 - Toshiba

TLP3107 Details

• Manufacturer Part Number:

  TLP3107

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  SOP-6

• HTS Code:

  8541.40.95.00

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0

• Additional Feature:

  UL RECOGNIZED

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• Control Current:

  0.005 A

• Control Voltage:

  1.18 V

• Forward Current-Max:

  0.025 A

• Isolation Voltage-Max:

  1500 V

• Mounting Feature:

  SURFACE MOUNT

• Number of Elements:

  1

• On-State Current-Max:

  3.3 A

• On-state Resistance-Max:

  0.06 Ω

• Operating Temperature-Max:

  65 °C

• Operating Temperature-Min:

  -20 °C

• Optoelectronic Device Type:

  TRANSISTOR OUTPUT SSR

• Overall Height:

  2.1 mm

• Overall Length:

  6.3 mm

• Surface Mount:

  YES
