TLP523-2 - Toshiba

TLP523-2 Details

• Manufacturer Part Number:

  TLP523-2

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  DIP-8

• HTS Code:

  8541.40.80.00

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0.4

• Additional Feature:

  UL RECOGNIZED

• Coll-Emtr Bkdn Voltage-Min:

  55 V

• Configuration:

  SEPARATE, 2 CHANNELS WITH BUILT-IN DIODE AND RESISTOR

• Current Transfer Ratio-Min:

  500%

• Current Transfer Ratio-Nom:

  2000%

• Dark Current-Max:

  200 nA

• Forward Current-Max:

  0.05 A

• Forward Voltage-Max:

  1.3 V

• Isolation Voltage-Max:

  2500 V

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Elements:

  2

• On-State Current-Max:

  0.15 A

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -55 °C

• Optoelectronic Device Type:

  DARLINGTON OUTPUT OPTOCOUPLER

• Power Dissipation-Max:

  0.15 W

• Response Time-Max:

  0.000003 s

• Surface Mount:

  NO
