TMAG5273B2QDBVR - Texas Instruments

TMAG5273B2QDBVR Details

• Manufacturer Part Number:

  TMAG5273B2QDBVR

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SOT-23-6

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Body Breadth:

  1.6 mm

• Body Height:

  1.1 mm

• Body Length or Diameter:

  2.9 mm

• Housing:

  PLASTIC

• JESD-609 Code:

  e3

• Magnetic Field Range-Max:

  266 mT

• Magnetic Field Range-Min:

  -266 mT

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Current-Max:

  3 mA

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  2 mA

• Output Interface Type:

  2-WIRE INTERFACE

• Output Range:

  0-5.5V

• Output Type:

  VOLTAGE OUTPUT

• Package Equivalence Code:

  TSOP6,.11,37

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  MAGNETIC FIELD SENSOR,HALL EFFECT

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  1.7 V

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn) - annealed

• Termination Type:

  SOLDER
