TMCS1101A1UQDR - Texas Instruments

TMCS1101A1UQDR Details

• Manufacturer Part Number:

  TMCS1101A1UQDR

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Date Of Intro:

  2020-05-31

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Body Breadth:

  3.895 mm

• Body Height:

  1.75 mm

• Body Length or Diameter:

  4.905 mm

• JESD-609 Code:

  e3

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Type:

  ANALOG VOLTAGE

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP8,.23

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  CURRENT SENSOR

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  3 V

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn)
