The TNY267GN is a 6.5W offline switcher IC, but the maximum output power depends on the specific application and design. Typically, it can handle up to 5W of output power with a suitable transformer and component selection.
The TNY267GN has a specified operating temperature range of -40°C to 150°C. Ensure proper thermal design, including a suitable heat sink and PCB layout, to keep the IC within this range. Monitor the IC's temperature and adjust the design as needed.
The recommended transformer design for the TNY267GN involves using a transformer with a turns ratio of 1:1.2 to 1:1.5, and a magnetizing inductance of at least 1.5μH. The transformer should also have a suitable core material and be designed for the specific application's voltage and current requirements.
Optimize the feedback loop by selecting the correct feedback resistors and capacitors, and ensuring the loop gain is sufficient. A good starting point is to use a feedback resistor of 2.2kΩ and a capacitor of 1nF. Adjust these values based on the specific application's requirements and stability analysis.
Key considerations for EMI filtering and compliance include using a suitable EMI filter, such as a common-mode choke and Y-capacitors, and ensuring the PCB layout is designed to minimize radiated emissions. Additionally, follow the guidelines for conducted emissions and ensure the design meets the relevant regulatory standards.
