TNY279PN footprint, schematic symbol and 3D model by Power Integrations

Symbol

click to zoom

PCB Footprints

TNY279PN - Power Integrations PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - LNK623PG

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for TNY279PN
Part Number TNY279PN
Manufacturer Power Integrations
Pin Count 8
Part Category Integrated Circuit
Package Category Dual-In-Line Packages
Footprint Name Dual-In-Line Packages - LNK623PG
Released Date Oct 16, 2019
Last Modified Date Mar 7, 2023 4:10 PM UTC
Pinout / Pin List Click Here (Member Only)

TNY279PN Details

Manufacturer Part Number:
TNY279PN
Rohs Code:
Yes
Part Life Cycle Code:
Active
Part Package Code:
DIP
Pin Count:
8
ECCN Code:
EAR99
HTS Code:
8542.39.00.60
Factory Lead Time:
8 Weeks
Manufacturer:
Power Integrations
YTEOL:
7
Adjustable Threshold:
NO
Analog IC - Other Type:
LOAD SWITCH
JESD-30 Code:
R-PDIP-T7
JESD-609 Code:
e3
Length:
9.575 mm
Number of Channels:
1
Number of Functions:
1
Number of Terminals:
7
Operating Temperature-Max:
125 °C
Operating Temperature-Min:
-40 °C
Package Body Material:
PLASTIC/EPOXY
Package Code:
DIP
Package Equivalence Code:
DIP7/8,.3
Package Shape:
RECTANGULAR
Package Style:
IN-LINE
Qualification Status:
Not Qualified
Supply Voltage-Max (Vsup):
265 V
Supply Voltage-Min (Vsup):
85 V
Supply Voltage-Nom (Vsup):
230 V
Surface Mount:
NO
Temperature Grade:
AUTOMOTIVE
Terminal Finish:
Matte Tin (Sn)
Terminal Form:
THROUGH-HOLE
Terminal Pitch:
2.54 mm
Terminal Position:
DUAL
Threshold Voltage-Nom:
+2.6V
Width:
7.62 mm

TNY279PN Frequently Asked Questions (FAQs)

The TNY279PN is a 700 V, 7.5 W offline switcher IC, which means it can handle a maximum output power of 7.5 W.
The TNY279PN has a junction temperature range of -40°C to 150°C. Ensure good thermal design, use a suitable heat sink, and follow the recommended PCB layout to maintain a stable temperature.
The BYPASS pin is used to connect an external bypass capacitor to filter the internal voltage regulator output, reducing noise and improving overall system stability.
Choose a transformer with a suitable turns ratio, core material, and wire size to ensure efficient energy transfer. Consult the Power Integrations application notes and transformer manufacturers' guidelines for selection criteria.
Follow a star-grounding scheme, keep high-voltage nodes away from low-voltage nodes, and use a solid ground plane to minimize EMI and ensure reliable operation.

Trust Checks

Community Provided

System Verified

Community Approved

TNY279PN Overview

Use the download button to access the TNY279PN schematic symbol and PCB footprint.
