TNY286PG Frequently Asked Questions (FAQs)

• What is the maximum output power that the TNY286PG can handle?
  The TNY286PG is a 6-pin, energy-efficient, offline switcher IC that can handle up to 6.5 W of output power.
• How do I ensure the TNY286PG operates within a stable temperature range?
  The TNY286PG has a built-in thermal shutdown feature that turns off the device when the junction temperature exceeds 150°C. Ensure good thermal design and heat sinking to keep the device within a stable temperature range.
• What is the recommended input voltage range for the TNY286PG?
  The recommended input voltage range for the TNY286PG is 85-265 VAC, with a maximum input voltage of 300 VAC.
• How do I optimize the design for EMI compliance?
  To optimize the design for EMI compliance, follow the layout guidelines in the datasheet, use a common-mode choke, and ensure proper grounding and shielding. Additionally, use a snubber network to reduce EMI emissions.
• What is the purpose of the BYPASS pin on the TNY286PG?
  The BYPASS pin is used to connect an external bypass capacitor to the internal voltage regulator, which helps to reduce noise and improve the overall power supply performance.
