TOP271KG - Power Integrations

Description: AC/DC Converter 66W eSOP-12 Power Integrations TOP271KG, AC-DC Converter 7A, 5 V dc, 11-Pin, eSOP-12

Download TOP271KG Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TOP271KG - Power Integrations PCB footprint - Other - Other - TOP271KG-2
click to zoom
3D Models
TOP271KG - Power Integrations  - 3D model - Other - TOP271KG-2
click to zoom

TOP271KG Details

  • Manufacturer Part Number:

    TOP271KG

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    Power Integrations

  • YTEOL:

    0

  • Analog IC - Other Type:

    LOAD SWITCH

  • JESD-609 Code:

    e3

  • Moisture Sensitivity Level:

    3

  • Peak Reflow Temperature (Cel):

    260

  • Terminal Finish:

    Matte Tin (Sn)

  • Time@Peak Reflow Temperature-Max (s):

    40

TOP271KG Frequently Asked Questions (FAQs)

  • The maximum output power of the TOP271KG is 270W, but it can be derated based on the input voltage, output voltage, and ambient temperature.
  • The transformer should be designed to meet the output power and voltage requirements of the application. The datasheet provides guidelines for transformer design, including the recommended turns ratio, magnetizing inductance, and leakage inductance.
  • The BYPASS pin is used to connect an external bypass capacitor to improve the power supply's noise immunity and reduce electromagnetic interference (EMI).
  • The TOP271KG has a built-in OVP circuit that can be enabled by connecting a resistor and capacitor to the OVP pin. The datasheet provides a design example and calculation for the OVP circuit components.
  • Yes, the TOP271KG is suitable for flyback converter topologies. However, the designer should ensure that the transformer is designed to meet the specific requirements of the flyback topology, including the primary and secondary turns ratio, magnetizing inductance, and leakage inductance.
