TP5089N - Texas Instruments

TP5089N Details

• Manufacturer Part Number:

  TP5089N

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  DIP

• Package Description:

  DIP, DIP16,.3

• Pin Count:

  16

• Reach Compliance Code:

  Unknown

• HTS Code:

  8542.39.00.01

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Crystal Frequency:

  3.579545 MHz

• JESD-30 Code:

  R-PDIP-T16

• Length:

  21.755 mm

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -30 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DIP

• Package Equivalence Code:

  DIP16,.3

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Seated Height-Max:

  5.08 mm

• Supply Current-Max:

  2.5 mA

• Supply Voltage-Nom:

  4 V

• Surface Mount:

  NO

• Technology:

  CMOS

• Telecom IC Type:

  TELEPHONE DIALER CIRCUIT

• Temperature Grade:

  OTHER

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Width:

  7.62 mm
