TPCW-233+ - Mini-Circuits

Description: RF Balun 0Hz ~ 23GHz 7W , 6-SMD, No Lead , -55°C to +125°C

Download TPCW-233+ Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TPCW-233+ - Mini-Circuits PCB footprint - Other - Other - JC0603C_2025-1.1
click to zoom
3D Models
TPCW-233+ - Mini-Circuits  - 3D model - Other - JC0603C_2025-1.1
click to zoom

TPCW-233+ Details

  • Manufacturer Part Number:

    TPCW-233+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Manufacturer:

    Mini-Circuits

  • RF/Microwave Device Type:

    THRU-LINE
