TPD4144AK - Toshiba

TPD4144AK Details

• Manufacturer Part Number:

  TPD4144AK

• Part Life Cycle Code:

  End Of Life

• Package Description:

  13 X 32 MM, 2 MM PITCH, PLASTIC, HDIP-26

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  Toshiba America Electronic Components

• YTEOL:

  0.4

• Additional Feature:

  ALSO NEED SUPPLY 50 TO 450V; SEATED HGT-CALCULATED

• Analog IC - Other Type:

  1-PHASE BRUSHLESS DC MOTOR CONTROLLER

• JESD-30 Code:

  R-PDIP-T26

• Length:

  32 mm

• Number of Functions:

  1

• Number of Terminals:

  26

• Output Current-Max:

  3 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HDIP

• Package Equivalence Code:

  DIP26(UNSPEC)

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE, HEAT SINK/SLUG

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  4 mm

• Supply Current-Max (Isup):

  5 mA

• Supply Voltage-Max (Vsup):

  16.5 V

• Supply Voltage-Min (Vsup):

  13.5 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Technology:

  MOS

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL

• Width:

  15.24 mm
