TPD5S115YFFR - Texas Instruments

Description: HDMI Companion Chip With Step-Up DC-DC Converter, Level Shifter, and ESD Clamp

Download TPD5S115YFFR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
TPD5S115YFFR - Texas Instruments PCB footprint - BGA - BGA - YFF0016  1
click to zoom
3D Models
TPD5S115YFFR - Texas Instruments  - 3D model - BGA - YFF0016  1
click to zoom

TPD5S115YFFR Details

  • Manufacturer Part Number:

    TPD5S115YFFR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Philippines

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Analog IC - Other Type:

    ANALOG CIRCUIT

  • JESD-30 Code:

    S-PBGA-B16

  • JESD-609 Code:

    e1

  • Length:

    1.738 mm

  • Moisture Sensitivity Level:

    1

  • Number of Channels:

    5

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    VFBGA

  • Package Shape:

    SQUARE

  • Package Style:

    GRID ARRAY, VERY THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Seated Height-Max:

    0.625 mm

  • Supply Voltage-Max (Vsup):

    3.6 V

  • Supply Voltage-Min (Vsup):

    1.2 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Tin/Silver/Copper (Sn/Ag/Cu)

  • Terminal Form:

    BALL

  • Terminal Pitch:

    0.4 mm

  • Terminal Position:

    BOTTOM

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    1.738 mm

TPD5S115YFFR Frequently Asked Questions (FAQs)

  • The maximum operating temperature range for the TPD5S115YFFR is -40°C to 125°C.
  • To prevent damage to the ESD protection diodes, handle the device by the package body, avoid touching the pins, and use an anti-static wrist strap or mat during assembly.
  • To minimize signal degradation, use a multi-layer PCB with a solid ground plane, keep signal traces short and away from noise sources, and use a 50-ohm transmission line impedance.
  • Yes, the TPD5S115YFFR is suitable for high-speed signal applications up to 3.2 Gbps, but ensure proper PCB layout and signal termination to minimize signal degradation.
  • The optimal value for R1 depends on the specific application and signal requirements. A general guideline is to use a value between 1 kΩ to 10 kΩ, but consult the datasheet and application notes for more information.
