TPF147-TR - 3Peak Incorporated

TPF147-TR Details

• Manufacturer Part Number:

  TPF147-TR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  SOT-23, 6 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  3peak Incorporated

• Additional Feature:

  SELECTABLE HD/FHD CHANNEL

• Bandwidth-Nom:

  71500 kHz

• Consumer IC Type:

  VIDEO AMPLIFIER

• Harmonic Distortion:

  0.15%

• JESD-30 Code:

  R-PDSO-G6

• Length:

  2.92 mm

• Moisture Sensitivity Level:

  3

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LSSOP

• Package Equivalence Code:

  TSOP6,.11,37

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, LOW PROFILE, SHRINK PITCH

• Packing Method:

  TR, 7 INCH

• Seated Height-Max:

  1.25 mm

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  3 V

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.95 mm

• Terminal Position:

  DUAL

• Width:

  1.6 mm
