The maximum operating temperature range for the TPS2815DR is -40°C to 125°C. However, it's recommended to operate within -40°C to 85°C for optimal performance and reliability.
To ensure proper power-up and initialization, make sure to follow the recommended power-up sequence: VCC, then EN, and finally IN. Also, ensure that the input voltage is within the recommended range and that the output capacitor is properly sized.
To minimize EMI and noise, place the TPS2815DR close to the input capacitors and keep the input and output traces short and separate. Use a solid ground plane and avoid routing sensitive signals near the switching node. Also, consider using a shielded inductor and a common-mode choke to reduce EMI.
To calculate the output voltage ripple, use the following formula: ΔVout = (Iout * ESL) / (Cout * fsw), where ESL is the equivalent series inductance of the output capacitor, Cout is the output capacitance, and fsw is the switching frequency. Ensure that the calculated ripple is within your application's requirements by selecting the appropriate output capacitor and inductor values.
When selecting input and output capacitors, consider the following factors: voltage rating, capacitance value, equivalent series resistance (ESR), and equivalent series inductance (ESL). Choose capacitors with low ESR and ESL to minimize losses and ensure stable operation. Also, ensure that the capacitors are rated for the maximum operating temperature and meet the required ripple current rating.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS2815DR Overview
Use the download button to access the TPS2815DR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS28,
or try a keyword search, such as MOSFET Drivers
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
