Texas Instruments provides a recommended PCB layout in the datasheet, but it's also important to follow general best practices for switching regulator layout, such as keeping the input and output capacitors close to the IC, using a solid ground plane, and minimizing trace lengths and widths.
The selection of the inductor depends on the specific requirements of your application, including the output voltage, output current, and switching frequency. Texas Instruments provides a list of recommended inductors in the datasheet, but you may also need to consider factors such as inductor core material, size, and saturation current.
The TPS51463RGET is rated for operation up to 105°C ambient temperature, but the actual operating temperature may be limited by the specific application and the thermal design of the system.
To ensure the stability of the output voltage, it's important to follow the recommended component values and PCB layout, and to ensure that the input voltage is within the specified range. Additionally, you may need to add additional capacitance or filtering to the output to reduce noise and ripple.
The TPS51463RGET is rated for input voltages up to 18V, but it's recommended to operate within the specified range of 4.5V to 15V for optimal performance and reliability.
