SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Cel):
260
Qualification Status:
Not Qualified
Screening Level:
AEC-Q100
Seated Height-Max:
1.2 mm
Supply Voltage-Max (Vsup):
6 V
Supply Voltage-Min (Vsup):
3 V
Surface Mount:
YES
Switcher Configuration:
BUCK
Switching Frequency-Max:
762 kHz
Technology:
BICMOS
Temperature Grade:
AUTOMOTIVE
Terminal Finish:
Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form:
GULL WING
Terminal Pitch:
0.65 mm
Terminal Position:
DUAL
Time@Peak Reflow Temperature-Max (s):
30
Width:
4.4 mm
TPS54372QPWPRQ1 Frequently Asked Questions (FAQs)
The maximum input voltage that can be applied to the TPS54372QPWPRQ1 is 60V, but it's recommended to operate within the specified input voltage range of 12V to 42V for optimal performance and reliability.
To ensure the TPS54372QPWPRQ1 operates within its thermal limits, you should provide adequate heat sinking, such as a thermal pad or heat sink, and ensure good airflow around the device. You should also monitor the junction temperature (TJ) and adjust the operating conditions accordingly.
The recommended layout and placement for the TPS54372QPWPRQ1 involves placing the input capacitors close to the VIN pin, keeping the high-current paths short and wide, and avoiding vias under the device. It's also recommended to follow the layout guidelines provided in the datasheet and application notes.
To troubleshoot issues with the TPS54372QPWPRQ1, you should first check the input voltage, output voltage, and current levels to ensure they are within the specified ranges. You should also check the thermal performance, PCB layout, and component selection. If the issue persists, you may need to consult the datasheet, application notes, and Texas Instruments' support resources for further guidance.
Yes, the TPS54372QPWPRQ1 is qualified for automotive and high-reliability applications, and it meets the requirements of the AEC-Q100 standard. However, you should ensure that the device is used within its specified operating conditions and that the system design meets the required safety and reliability standards.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS54372QPWPRQ1 Overview
Use the download button to access the TPS54372QPWPRQ1 schematic symbol, PCB footprint, and 3D model.
