Texas Instruments provides a recommended PCB layout in the datasheet, but it's also important to follow general best practices for switching regulator layout, such as keeping the input and output capacitors close to the IC, using a solid ground plane, and minimizing trace lengths and widths.
The choice of inductor depends on the specific requirements of your application, including the input voltage, output voltage, and output current. TI provides a list of recommended inductors in the datasheet, but you may also need to consider factors such as inductor size, core material, and saturation current.
While the datasheet specifies an operating temperature range of -40°C to 125°C, the maximum ambient temperature for reliable operation depends on the specific application and the thermal design of the system. It's recommended to perform thermal analysis and testing to ensure reliable operation in your specific use case.
To ensure stability and prevent oscillations, follow the recommended component values and PCB layout guidelines in the datasheet. Additionally, consider using a compensation network to stabilize the feedback loop, and perform simulation and testing to verify the stability of your design.
The recommended input capacitor type and value depend on the specific application and input voltage. In general, a low-ESR ceramic capacitor with a value of 10uF to 22uF is recommended. However, it's important to consider the input voltage ripple and noise requirements of your application when selecting the input capacitor.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS61052YZGR Overview
Use the download button to access the TPS61052YZGR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS61,
or try a keyword search, such as Display Drivers
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
