A good PCB layout for the TPS8268180SIPT involves placing the input capacitors close to the VIN pin, using a solid ground plane, and keeping the high-current paths short and wide. It's also recommended to use a 4-layer PCB with a dedicated power plane and a dedicated ground plane.
When choosing an inductor for the TPS8268180SIPT, consider the inductor's saturation current, DC resistance, and core material. A good starting point is to use an inductor with a saturation current of at least 2A, a DC resistance of less than 100mΩ, and a ferrite or iron powder core.
The TPS8268180SIPT is rated for operation from -40°C to 125°C, but the maximum ambient temperature range depends on the specific application and the device's power dissipation. In general, it's recommended to keep the ambient temperature below 85°C for reliable operation.
The TPS8268180SIPT has a built-in overcurrent protection feature that can be enabled by connecting a resistor from the OCSET pin to GND. The value of the resistor determines the overcurrent threshold. A good starting point is to use a 10kΩ resistor, which sets the overcurrent threshold to around 2.5A.
Yes, the TPS8268180SIPT is qualified for automotive and high-reliability applications. It meets the requirements of the AEC-Q100 standard and is manufactured using a robust process that ensures high reliability and low defect rates.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS8268180SIPT Overview
Use the download button to access the TPS8268180SIPT schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS82,
or try a keyword search, such as Switching Regulator or Controllers
