Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow the guidelines for thermal vias, copper pours, and component placement to ensure optimal heat dissipation. A good rule of thumb is to use a minimum of 2oz copper thickness and to place thermal vias under the device.
The input capacitor selection depends on the input voltage, output voltage, and output current. A general guideline is to choose a capacitor with a voltage rating of at least 1.5 times the input voltage, and a capacitance value of 10uF to 22uF. X5R or X7R ceramic capacitors are recommended due to their low ESR and high reliability.
The maximum ambient temperature for the TPS92365xDMTR is 85°C. As the ambient temperature increases, the device's performance may degrade, and the output voltage may drop. It's essential to ensure proper heat sinking and airflow to maintain a safe operating temperature.
Yes, the TPS92365xDMTR is AEC-Q100 qualified, making it suitable for automotive applications. Additionally, it's manufactured using a high-reliability process, making it suitable for use in high-reliability applications. However, it's essential to follow the recommended operating conditions and design guidelines to ensure the device meets the required reliability standards.
To troubleshoot issues with the TPS92365xDMTR, start by verifying the input voltage, output voltage, and output current. Check for proper PCB layout, component selection, and thermal design. Use oscilloscopes and thermal cameras to identify any anomalies. Consult the datasheet and application notes for guidance on troubleshooting and debugging.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TPS923652DMTR Overview
Use the download button to access the TPS923652DMTR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TPS92,
or try a keyword search, such as Display Drivers
