TR3D337K6R3C0050 - Vishay

TR3D337K6R3C0050 Details

• Manufacturer Part Number:

  TR3D337K6R3C0050

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  CHIP

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• HTS Code:

  8532.21.00.50

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  6.98

• Additional Feature:

  ESR AND RIPPLE CURRENT IS MEASURED AT 100KHZ

• Capacitance:

  330 µF

• Capacitor Type:

  TANTALUM CAPACITOR

• Dielectric Material:

  TANTALUM (DRY/SOLID)

• ESR:

  50 mΩ

• Height:

  2.8 mm

• JESD-609 Code:

  e3

• Leakage Current:

  0.020800000000000003 mA

• Length:

  7.3 mm

• Mounting Feature:

  SURFACE MOUNT

• Negative Tolerance:

  10%

• Number of Terminals:

  2

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Shape:

  RECTANGULAR PACKAGE

• Package Style:

  SMT

• Packing Method:

  TR, EMBOSSED PLASTIC, 7 INCH

• Polarity:

  POLARIZED

• Positive Tolerance:

  10%

• Rated (DC) Voltage (URdc):

  6.3 V

• Ripple Current:

  692 mA

• Size Code:

  2917

• Surface Mount:

  YES

• Tan Delta:

  0.08

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Shape:

  J BEND

• Width:

  4.3 mm
