TS3A226AEYFFR - Texas Instruments

TS3A226AEYFFR Details

• Manufacturer Part Number:

  TS3A226AEYFFR

• Brand Name:

  Texas Instruments

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.90

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Additional Feature:

  Configuration : Audio jack

• Analog IC - Other Type:

  AUDIO/VIDEO SWITCH

• Bandwidth-Nom:

  200 MHz

• Input Voltage-Max:

  4.5 V

• Input Voltage-Min:

  2.6 V

• JESD-30 Code:

  S-XBGA-B9

• JESD-609 Code:

  e1

• Length:

  1.4 mm

• Moisture Sensitivity Level:

  1

• Normal Position:

  NO

• Number of Channels:

  1

• Number of Functions:

  2

• Number of Terminals:

  9

• Off-state Isolation-Nom:

  80 dB

• On-state Resistance-Max (Ron):

  85 Ω

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output:

  SEPARATE OUTPUT

• Package Body Material:

  UNSPECIFIED

• Package Code:

  VFBGA

• Package Equivalence Code:

  BGA9,3X3,16

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• Qualification Status:

  Not Qualified

• Seated Height-Max:

  0.425 mm

• Supply Current-Max (Isup):

  0.014 mA

• Supply Voltage-Max (Vsup):

  4.7 V

• Supply Voltage-Min (Vsup):

  2.6 V

• Supply Voltage-Nom (Vsup):

  3.3 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)

• Terminal Form:

  BALL

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  1.4 mm
