The recommended land pattern for the TSL0808RA-102KR26-PF can be found in the TDK Corporation's application note or the IPC-7351 standard. It's essential to follow the recommended land pattern to ensure proper soldering and to prevent thermal and mechanical stress on the component.
During reflow soldering, it's crucial to follow the recommended temperature profile to prevent damage to the component. The maximum temperature rating for the TSL0808RA-102KR26-PF is 260°C. It's also essential to ensure proper solder paste printing, component placement, and reflow oven setup to prevent defects and ensure reliable solder joints.
The maximum operating temperature range for the TSL0808RA-102KR26-PF is -55°C to 125°C. However, it's essential to note that the component's performance and reliability may degrade if operated at extreme temperatures. It's recommended to operate the component within the recommended temperature range for optimal performance and reliability.
The TSL0808RA-102KR26-PF is designed to withstand moderate vibration levels. However, it's essential to ensure that the component is properly mounted and secured to the PCB to prevent mechanical stress and damage. If the application requires extreme vibration resistance, it's recommended to consult with TDK Corporation or a qualified engineer to determine the component's suitability.
To prevent damage, it's essential to store the TSL0808RA-102KR26-PF in a dry, cool place, away from direct sunlight and moisture. The component should be handled with care to prevent mechanical stress, bending, or twisting. It's recommended to follow the ESD (Electrostatic Discharge) precautions when handling the component to prevent electrical damage.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TSL0808RA-102KR26-PF Overview
Use the download button to access the TSL0808RA-102KR26-PF schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TSL08,
or try a keyword search, such as Fixed Inductors
