TSM250NB06LDCRRLG - Taiwan Semiconductor

TSM250NB06LDCRRLG Details

• Manufacturer Part Number:

  TSM250NB06LDCRRLG

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN56, 8 PIN

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• Date Of Intro:

  2020-01-20

• Manufacturer:

  Taiwan Semiconductor

• YTEOL:

  5

• Avalanche Energy Rating (Eas):

  25 mJ

• Case Connection:

  DRAIN

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  60 V

• Drain Current-Max (ID):

  6 A

• Drain-source On Resistance-Max:

  0.025 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• Feedback Cap-Max (Crss):

  26 pF

• JESD-30 Code:

  R-PDSO-F8

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  8

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation Ambient-Max:

  2 W

• Power Dissipation-Max (Abs):

  48 W

• Pulsed Drain Current-Max (IDM):

  116 A

• Reference Standard:

  IEC-61249-2-21

• Surface Mount:

  YES

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
