A good PCB layout for the TVA1713 should ensure that the input and output pins are separated as much as possible to minimize coupling. Additionally, a solid ground plane and short, direct traces to the input and output capacitors are recommended. A 4-layer PCB with a dedicated power plane and a separate ground plane is ideal.
The input capacitor should be a low-ESR, high-frequency capacitor (e.g., X7R or X5R dielectric) with a value between 1-10uF. The output capacitor should be a low-ESR, high-frequency capacitor (e.g., X7R or X5R dielectric) with a value between 10-22uF. The capacitor values and types may vary depending on the specific application and operating conditions.
The TVA1713 is rated for operation from -40°C to +125°C. However, the device's performance and reliability may degrade at extreme temperatures. It's essential to ensure that the device operates within the recommended temperature range for optimal performance and reliability.
To ensure stability, follow the recommended PCB layout guidelines, use the correct input and output capacitors, and ensure that the input voltage is within the recommended range. Additionally, a small resistor (e.g., 10-20 ohms) in series with the input capacitor can help to dampen any oscillations.
The recommended input voltage range for the TVA1713 is 2.7V to 5.5V. Operating the device outside of this range may affect its performance, stability, and reliability.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TVA1713 Overview
Use the download button to access the TVA1713 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TVA17,
or try a keyword search, such as Aluminum Electrolytic Capacitors
