A good PCB layout for the TVS2701DRBR involves placing the device close to the protected circuit, using short and wide traces, and minimizing the distance between the device and the protected circuit. Additionally, a solid ground plane and a low-impedance path to the ground are recommended.
To choose the correct TVS2701DRBR, consider the maximum voltage and current requirements of your application, as well as the desired level of protection. The TVS2701DRBR is available in different voltage and current ratings, so select the one that best matches your application's needs.
The TVS2701DRBR has an operating temperature range of -40°C to 125°C. However, the device's performance and reliability may degrade if operated outside the recommended temperature range.
Yes, the TVS2701DRBR is suitable for high-frequency applications. It has a low capacitance of 0.4 pF, making it suitable for high-frequency circuits. However, the device's performance may degrade at very high frequencies (>1 GHz).
To ensure proper soldering, follow the recommended soldering profile and use a solder with a melting point below 260°C. Avoid overheating the device, and use a soldering iron with a temperature control to prevent damage to the device.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
TVS2701DRBR Overview
Use the download button to access the TVS2701DRBR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like TVS27,
or try a keyword search, such as Transient Suppressors
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
