IT ALSO CAN OPERATE WITH 2.95 VSIM SUPPLY;,PUSH PULL OUTPUT ALSO AVAILABLE
Interface IC Type:
VOLTAGE LEVEL TRANSLATOR
JESD-30 Code:
S-PQCC-N24
JESD-609 Code:
e4
Length:
4 mm
Moisture Sensitivity Level:
1
Number of Bits:
6
Number of Functions:
1
Number of Terminals:
24
Operating Temperature-Max:
85 °C
Operating Temperature-Min:
-40 °C
Output Characteristics:
OPEN-DRAIN
Output Polarity:
TRUE
Package Body Material:
PLASTIC/EPOXY
Package Code:
HVQCCN
Package Equivalence Code:
LCC24,.16SQ,20
Package Shape:
SQUARE
Package Style:
CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Cel):
260
Qualification Status:
Not Qualified
Seated Height-Max:
1 mm
Supply Current-Max:
0.005 mA
Supply Voltage-Max:
3.3 V
Supply Voltage-Min:
1.7 V
Supply Voltage-Nom:
1.8 V
Supply Voltage1-Nom:
1.8 V
Surface Mount:
YES
Temperature Grade:
INDUSTRIAL
Terminal Finish:
Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form:
NO LEAD
Terminal Pitch:
0.5 mm
Terminal Position:
QUAD
Time@Peak Reflow Temperature-Max (s):
30
Width:
4 mm
TXS02326AMRGER Frequently Asked Questions (FAQs)
Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow good layout practices, such as keeping the signal traces short, using a solid ground plane, and avoiding vias under the device. Additionally, ensure the decoupling capacitors are placed close to the device and connected to the power pins.
The TXS02326AMRGER has a thermal pad on the bottom, which should be connected to a thermal plane on the PCB. Ensure good thermal conductivity by using a thermal interface material (TIM) and a heat sink if necessary. Keep the device away from heat sources and ensure good airflow around the device.
The TXS02326AMRGER is specified to operate up to 100 MHz, but it can be overclocked to higher frequencies with careful design and layout considerations. However, this may affect the device's reliability and performance.
To ensure signal integrity, use controlled impedance traces, and terminate the signals properly. Use a signal integrity analysis tool to simulate the signal behavior and optimize the design accordingly. Additionally, ensure the device is properly decoupled, and the power supply is clean and stable.
The TXS02326AMRGER requires a specific power sequencing to ensure proper operation. The VCC pin should be powered up before the VREF pin, and the VREF pin should be powered up before the input signals. Ensure the power supply is stable and clean before applying input signals.
