U86-D4427-10121 - Amphenol

U86-D4427-10121 Details

• Manufacturer Part Number:

  U86-D4427-10121

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Amphenol Corporation

• YTEOL:

  7

• Additional Feature:

  8 PORTS, 20 POSITIONS EACH, SHIELDED

• Board Mounting Option:

  HOLE 0.041

• Body Breadth:

  1.002 inch

• Body Depth:

  2.485 inch

• Body Length:

  2.451 inch

• Connector Type:

  SFP CONNECTOR

• Contact Gender:

  FEMALE

• Contact Pattern:

  STAGGERED

• Contact Resistance:

  70 mΩ

• Contact Style:

  SFP+ TYPE

• Dielectric Withstanding Voltage:

  300VAC V

• Durability:

  250 Cycles

• Empty Shell:

  NO

• Filter Feature:

  NO

• Insulation Resistance:

  1000000000 Ω

• Insulator Material:

  GLASS FILLED POLYETHYLENE

• Mixed Contacts:

  NO

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of PCB Rows:

  4+4

• Number of Ports:

  8

• Number of Rows Loaded:

  2+2

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Option:

  GENERAL PURPOSE

• PCB Contact Pattern:

  STAGGERED

• Plating Thickness:

  30u inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  0.5 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL/TIN

• Shell Material:

  COPPER ALLOY

• Terminal Length:

  0.078 inch

• Terminal Pitch:

  1.6 mm

• Termination Type:

  PRESS FIT

• Total Number of Contacts:

  160

• UL Flammability Code:

  94V-0
