The UC2845AQD8 is a high-frequency switching regulator, and proper PCB layout is crucial for its operation. TI recommends a multi-layer PCB with a solid ground plane, and the use of vias to connect the top and bottom layers. The input and output capacitors should be placed close to the IC, and the feedback network should be routed away from the switching node.
The choice of inductor depends on the output voltage, current, and switching frequency. TI recommends using an inductor with a high saturation current rating, low DC resistance, and a high self-resonant frequency. The inductor value should be chosen to ensure that the peak inductor current is within the recommended range.
The UC2845AQD8 is rated for operation from -40°C to 85°C. However, the device may be derated for operation above 70°C, and the user should ensure that the junction temperature does not exceed 150°C.
The UC2845AQD8 requires a compensation network to ensure stability. TI recommends using a type-III compensation network, which consists of a series resistor and capacitor, and a parallel capacitor. The values of these components depend on the output voltage, current, and switching frequency.
TI recommends using a low-ESR ceramic or film capacitor with a value of at least 10uF for the input capacitor. The capacitor should be rated for the maximum input voltage and should be placed close to the IC.
