Texas Instruments provides a recommended PCB layout in the application note SLUA945, which includes guidelines for component placement, routing, and thermal management to ensure optimal performance and minimize electromagnetic interference (EMI).
The selection of the transformer depends on the specific application requirements, such as output power, voltage, and frequency. Texas Instruments provides a transformer selection guide in the application note SLUA944, which includes guidelines for selecting the right transformer and calculating the transformer's turns ratio, inductance, and leakage inductance.
The maximum operating temperature range for UCC28782ARTWR is -40°C to 125°C, as specified in the datasheet. However, the device's performance and reliability may be affected at extreme temperatures, and it is recommended to operate the device within a temperature range of 0°C to 85°C for optimal performance.
The UCC28782ARTWR has built-in OVP and UVP features, which can be enabled by connecting the OVP and UVP pins to the desired voltage threshold levels. The application note SLUA946 provides guidelines for implementing OVP and UVP using external components and programming the device's registers.
The recommended input capacitor value and type depend on the specific application requirements, such as input voltage, frequency, and ripple current. A general guideline is to use a low-ESR ceramic capacitor with a value of 10uF to 22uF, as specified in the application note SLUA945.
Trust Checks
This model has been verified by system checks.
System Verified
Sponsored
UCC28782ARTWR Overview
Use the download button to access the UCC28782ARTWR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like UCC28,
or try a keyword search, such as Switching Regulator or Controllers
