UCC33421DHAR - Texas Instruments

UCC33421DHAR Details

• Manufacturer Part Number:

  UCC33421DHAR

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Texas Instruments

• YTEOL:

  15

• Additional Feature:

  5.5VDC SELECTABLE OUTPUT ALSO AVAILABLE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Efficiency (Main Output):

  59%

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-PDSO-G16

• Length:

  7.5 mm

• Load Regulation-Max:

  0.8%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage-Max:

  5.7 V

• Output Voltage-Min:

  4.85 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SSOP

• Package Equivalence Code:

  SSOP16,.4

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, SHRINK PITCH

• Protections:

  OVER LOAD; OVER VOLTAGE; SHORT CIRCUIT; THERMAL; UNDER VOLTAGE

• Ripple Voltage (Main Out):

  0.0265125 Vrms

• Seated Height-Max:

  2.6 mm

• Surface Mount:

  YES

• Technology:

  HYBRID

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  1.5 W

• Trim/Adjustable Output:

  NO

• Width:

  5.85 mm
