A good PCB layout for the UCC3808APW-2 involves keeping the input and output stages separate, using a star-ground configuration, and placing the IC close to the input capacitors. Additionally, using a 4-layer PCB with a dedicated ground plane can help reduce EMI.
When selecting input capacitors for the UCC3808APW-2, consider the voltage rating, capacitance value, and ESR (Equivalent Series Resistance). A good starting point is to use low-ESR capacitors with a voltage rating of at least 1.5 times the maximum input voltage, and a capacitance value of 10-22uF.
The UCC3808APW-2 can deliver up to 2A of output current, but this depends on the input voltage, output voltage, and thermal conditions. It's essential to check the thermal derating curves in the datasheet to ensure the IC can deliver the required output current.
To synchronize the UCC3808APW-2 with an external clock signal, connect the clock signal to the SYNC pin. Ensure the clock signal is within the recommended frequency range (100kHz to 1MHz) and has a duty cycle of 50% ± 10%. Also, make sure to add a series resistor (1kΩ to 10kΩ) between the clock source and the SYNC pin.
The EN (Enable) pin on the UCC3808APW-2 is used to enable or disable the IC. When the EN pin is high (above 2.5V), the IC is enabled, and when it's low (below 0.8V), the IC is disabled. You can use the EN pin to implement power sequencing, shutdown, or low-power standby modes.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
UCC3808APW-2 Overview
Use the download button to access the UCC3808APW-2 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like UCC38,
or try a keyword search, such as Switching Regulator or Controllers
About Texas Instruments
Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
