UPA654TT-E2-A - Renesas Electronics

UPA654TT-E2-A Details

• Manufacturer Part Number:

  UPA654TT-E2-A

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  WSOF

• Package Description:

  LEAD FREE, WSOF, 6 PIN

• Pin Count:

  6

• Manufacturer Package Code:

  PWSF0006JB-A6

• ECCN Code:

  5A002

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  12 V

• Drain Current-Max (ID):

  2.5 A

• Drain-source On Resistance-Max:

  0.133 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  R-PDSO-F6

• JESD-609 Code:

  e6

• Number of Elements:

  1

• Number of Terminals:

  6

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, EMBOSSED

• Polarity/Channel Type:

  P-CHANNEL

• Power Dissipation-Max (Abs):

  1.3 W

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Bismuth (Sn/Bi)

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
