V23030C1021A206 - TE Connectivity

V23030C1021A206 Details

• Manufacturer Part Number:

  V23030C1021A206

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  37.4 mm

• Body Height:

  10.2 mm

• Body Length or Diameter:

  39.7 mm

• Coil Current(DC)-Max:

  0.033 A

• Coil Power:

  789 mW

• Coil Resistance:

  730 Ω

• Coil Voltage(AC)-Max:

  30 V

• Coil Voltage(DC)-Max:

  36 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  2 A

• Contact Current(DC)-Max:

  2 A

• Contact Voltage(AC)-Max:

  36 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC/DC

• End Contact Material:

  GOLD

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX

• Physical Dimension:

  39.7 X 37.4 X 10.2

• Relay Action:

  MOMENTARY

• Relay Form:

  6 FORM C

• Relay Function:

  6PDT

• Relay Type:

  POWER/SIGNAL RELAY

• Sealing:

  DUST PROOF

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT
