V5N3M103-M3/I - Vishay

V5N3M103-M3/I Details

• Manufacturer Part Number:

  V5N3M103-M3/I

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DFN33A, 5 PIN

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Manufacturer:

  Vishay Intertechnologies

• YTEOL:

  6

• Additional Feature:

  FREE WHEELING DIODE, LOW POWER LOSS

• Application:

  EFFICIENCY

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  0.66 V

• JESD-30 Code:

  S-PDSO-N5

• Non-rep Pk Forward Current-Max:

  100 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  175 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  2.5 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Packing Method:

  TR, PLASTIC, 13 INCH

• Rep Pk Reverse Voltage-Max:

  100 V

• Reverse Current-Max:

  80 µA

• Reverse Test Voltage:

  100 V

• Surface Mount:

  YES

• Technology:

  SCHOTTKY

• Terminal Form:

  NO LEAD

• Terminal Position:

  DUAL
