VAA505 - Cosel

VAA505 Details

• Manufacturer Part Number:

  VAA505

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PACKAGE-5

• ECCN Code:

  EAR99

• Date Of Intro:

  2016-09-19

• Manufacturer:

  Cosel USA Inc

• YTEOL:

  0

• Additional Feature:

  ALSO OPERATE WITH 110-170VDC

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CUL, FCC, UL

• Efficiency (Main Output):

  75%

• Input Voltage-Max:

  132 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-XXMA-P5

• Length:

  65 mm

• Line Regulation-Max:

  0.001%

• Load Regulation-Max:

  0.8%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  5

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -10 °C

• Output Current-Max:

  1 A

• Output Voltage-Max:

  5.3 V

• Output Voltage-Min:

  4.9 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OVER CURRENT, OVER VOLTAGE

• Ripple Voltage (Main Out):

  0.05656 Vrms

• Seated Height-Max:

  19 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  UNSPECIFIED

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  5 W

• Trim/Adjustable Output:

  NO

• Width:

  32 mm
