VCB4812SO-6WR3 - Mornsun Power

VCB4812SO-6WR3 Details

• Manufacturer Part Number:

  VCB4812SO-6WR3

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  MORNSUN

• YTEOL:

  5

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE; CIS; EN; IEC; UKCA; UL

• Efficiency (Main Output):

  83%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XSIP-T7

• Length:

  22 mm

• Line Regulation-Max:

  1%

• Load Regulation-Max:

  1.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  7

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.5 A

• Output Voltage-Max:

  12.36 V

• Output Voltage-Min:

  11.64 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  SIP

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Protections:

  SHORT CIRCUIT; OVER CURRENT; UNDER VOLTAGE

• Ripple Voltage (Main Out):

  0.0707 Vrms

• Screening Level:

  EN 62368-1

• Seated Height-Max:

  13.3 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Total Power Output-Max:

  6 W

• Trim/Adjustable Output:

  NO

• Width:

  8.2 mm
