VF4-15F13 - TE Connectivity

VF4-15F13 Details

• Manufacturer Part Number:

  VF4-15F13

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.05

• Factory Lead Time:

  21 Weeks, 4 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  6.77

• Body Breadth:

  26.2 mm

• Body Height:

  26.2 mm

• Body Length or Diameter:

  26.2 mm

• Coil Current(DC)-Max:

  0.133 A

• Coil Operate Voltage(DC):

  7.2 V

• Coil Power:

  1600 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  90 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil Voltage-Nom:

  12 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  40 A

• Contact Current(DC)-Max:

  40 A

• Contact (DC) Max Rating R Load:

  1A@12VDC

• Contact Voltage(DC)-Max:

  12 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  Silver Nickel Oxide

• Input Switching Control Type:

  Random

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  7 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Physical Dimension:

  26.2mm x 26.2mm x 26.2mm

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM C

• Relay Function:

  SPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  2 ms

• Sealing:

  DUST PROOF

• Surface Mount:

  NO

• Termination Type:

  SOLDER
