VI-AIM-I1 - VICOR

VI-AIM-I1 Details

• Manufacturer Part Number:

  VI-AIM-I1

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  MODULE

• Package Description:

  HALF BRICK PACKAGE-9

• Pin Count:

  9

• ECCN Code:

  EAR99

• Factory Lead Time:

  22 Weeks

• Manufacturer:

  Vicor Corporation

• YTEOL:

  4

• Additional Feature:

  OPERATES FROM AN AC SUPPLY OF 85V TO 264V

• Analog IC - Other Type:

  AC-DC UNREGULATED POWER SUPPLY MODULE

• Approvals:

  UL, CSA, TUV, VDE

• Efficiency (Main Output):

  97%

• Input Voltage-Max:

  264 V

• Input Voltage-Min:

  85 V

• JESD-30 Code:

  R-XDMA-P9

• JESD-609 Code:

  e0

• Length:

  61 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage-Max:

  373 V

• Output Voltage-Min:

  120 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  250 W

• Trim/Adjustable Output:

  YES

• Width:

  57.9 mm
