VI-HAM-CM - VICOR

VI-HAM-CM Details

• Manufacturer Part Number:

  VI-HAM-CM

• Pbfree Code:

  No

• Part Life Cycle Code:

  Obsolete

• Package Description:

  PACKAGE-9

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Factory Lead Time:

  26 Weeks

• Manufacturer:

  Vicor Corporation

• YTEOL:

  0

• Additional Feature:

  ALSO IT HAS 365VDC O/P @ 230VAC

• Analog IC - Other Type:

  AC-DC POWER FACTOR CORRECTION MODULE

• Approvals:

  UL, EN, CSA

• Efficiency (Main Output):

  94%

• Input Voltage-Max:

  264 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  115 V

• JESD-30 Code:

  R-XDFM-P9

• JESD-609 Code:

  e0

• Length:

  116.8 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Output Voltage-Max:

  262 V

• Output Voltage-Min:

  258 V

• Output Voltage-Nom:

  260 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Protections:

  SHORT CIRCUIT

• Qualification Status:

  Not Qualified

• Ripple Voltage (Main Out):

  3.535 Vrms

• Seated Height-Max:

  13.46 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  COMMERCIAL EXTENDED

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  600 W

• Trim/Adjustable Output:

  NO

• Width:

  60.9 mm
