VIPER27LD - STMicroelectronics

Description: STMicroelectronics VIPER27LD, AC-DC Converter, 16-Pin, SOIC

Download VIPER27LD Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
VIPER27LD - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
VIPER27LD - STMicroelectronics PCB footprint - Small Outline Packages - Small Outline Packages - SO16 Narrow_1
click to zoom
3D Models
VIPER27LD - STMicroelectronics - 3D model - Small Outline Packages - SO16 Narrow_1
click to zoom

VIPER27LD Details

  • Manufacturer Part Number:

    VIPER27LD

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    SOIC

  • Package Description:

    ROHS COMPLIANT, SOP-16

  • Pin Count:

    16

  • Country Of Origin:

    Thailand

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    18 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    6

  • Analog IC - Other Type:

    SWITCHING CONTROLLER

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    23.5 V

  • Input Voltage-Min:

    8.5 V

  • Input Voltage-Nom:

    14 V

  • JESD-30 Code:

    R-PDSO-G16

  • JESD-609 Code:

    e4

  • Length:

    9.9 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    16

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    0.74 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP16,.4

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.75 mm

  • Surface Mount:

    YES

  • Switcher Configuration:

    SINGLE

  • Switching Frequency-Max:

    60 kHz

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3.9 mm

VIPER27LD Frequently Asked Questions (FAQs)

  • STMicroelectronics recommends a 4-layer PCB with a solid ground plane, and to keep the high-frequency components (e.g. transformer, diodes) close to the IC. A good layout should also ensure that the input and output stages are separated to minimize coupling.
  • The transformer should be designed to match the VIPER27LD's operating frequency (typically 65 kHz) and the desired output voltage. A good starting point is to use a transformer with a turns ratio of 1:1.2 to 1:1.5, and a magnetizing inductance of at least 10 μH.
  • The maximum allowed voltage on the VIN pin is 30 V, but it's recommended to keep it below 28 V to ensure reliable operation and to prevent damage to the IC.
  • To ensure SOA, monitor the IC's junction temperature (TJ) and keep it below 150°C. Also, ensure that the input voltage and current are within the recommended limits, and that the output voltage is not overloaded.
  • Yes, but with caution. The VIPER27LD is rated for operation up to 150°C, but its performance and reliability may degrade at high temperatures. Ensure that the IC is properly cooled, and consider using a heat sink or thermal interface material if necessary.
