VIPER27LN - STMicroelectronics

Description: STMicroelectronics VIPER27LN, SMPS Controller, 7-Pin, PDIP

Download VIPER27LN Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
VIPER27LN - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
VIPER27LN - STMicroelectronics PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - DIP-7
click to zoom
3D Models
VIPER27LN - STMicroelectronics - 3D model - Dual-In-Line Packages - DIP-7
click to zoom

VIPER27LN Details

  • Manufacturer Part Number:

    VIPER27LN

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    DIP

  • Package Description:

    ROHS COMPLIANT, DIP-8/7

  • Pin Count:

    7

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    18 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    5

  • Analog IC - Other Type:

    SWITCHING CONTROLLER

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    23.5 V

  • Input Voltage-Min:

    8.5 V

  • Input Voltage-Nom:

    14 V

  • JESD-30 Code:

    R-PDIP-T7

  • JESD-609 Code:

    e3

  • Length:

    9.27 mm

  • Number of Functions:

    1

  • Number of Terminals:

    7

  • Operating Temperature-Max:

    150 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Current-Max:

    0.74 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Equivalence Code:

    DIP7/8,.3

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Peak Reflow Temperature (Cel):

    NOT SPECIFIED

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    5.33 mm

  • Surface Mount:

    NO

  • Switcher Configuration:

    SINGLE

  • Switching Frequency-Max:

    60 kHz

  • Terminal Finish:

    Matte Tin (Sn) - annealed

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    NOT SPECIFIED

  • Width:

    7.62 mm

VIPER27LN Frequently Asked Questions (FAQs)

  • STMicroelectronics recommends a 4-layer PCB with a solid ground plane, and to keep the high-frequency components (e.g. transformer, diodes) close to the IC. A good layout should also ensure that the input and output stages are separated to minimize coupling.
  • The transformer should be designed to operate at the switching frequency of the VIPER27LN (typically 60-100 kHz). The transformer's turns ratio, inductance, and core material should be selected based on the input and output voltage requirements, and the desired power rating.
  • The maximum allowed voltage on the VIN pin is 30V, but it's recommended to keep it below 28V to ensure reliable operation and to prevent damage to the internal voltage regulator.
  • The VIPER27LN's SOA is defined by its maximum current, voltage, and power ratings. Ensure that the input voltage, output current, and power dissipation are within the recommended limits. Also, monitor the IC's temperature and adjust the design accordingly to prevent overheating.
  • The VCC pin is the power supply pin for the internal voltage regulator. It should be connected to a stable voltage source (e.g. a capacitor-filtered output of the switching converter) to ensure proper operation of the IC.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

VIPER27LN Overview

Use the download button to access the VIPER27LN schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like VIPER, or try a keyword search, such as Switching Regulator or Controllers
